Product Overview
TIC7626EL-GAF75-4X56-VH1
- • Thermal & Optical dual-spectrum image, dual video with single IP address, adaptable to more various scenes • Passive infrared thermal imaging, meet the requirement of concealed monitoring and not affected by bad weather condition such as fog, smoke, rain, snow and night etc.
- • Thermal channel supports fire detection, optical channel can link to the fire position and zoom in, more accurate to judge fire situation • Thermal or visible channel support smart intrusion prevention based on deep learning algorithm: cross line, enter area, leave area, intrusion, support smart tracking • Optical channel supports 4MP@60fps ,which has the smoother motion image • Optical channel supports Gyroscope stabilization for stable picture • Optical channel supports heat wave reduction which can reduce heat wave phenomenon and improve image quality • Vari-focal laser:800m(2624.
- 7ft) distance, proportional to optical zoom of camera module • Rain-sensing auto wiper ,provide clear image in harsh weather • Support 1/1 audio in/out, 7/2 alarm in/out ,1 Serial port RS485 • Power supply: DC 48V±25%、DC 24V±15%、AC 24V±25% • IP66.
Key Features
- N/A Resolution
- IR-cut filter with auto switch (ICR) Vision
Camera
Video & Audio
| Max Resolution | N/A | Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Sensor | 1/1.8" CMOS | Frame Rate | Main Stream: 2MP (1920*1080),Max 30fps; 720P (1280*720),Max 30fps Sub Stream: 640*360,Max 30fps; 2CI |
| Day/Night | IR-cut filter with auto switch (ICR) | Audio Compression | G.711U, G.711A |
| WDR | DWDR | Two-Way Audio | N/A |
Lens
General
| Focal Length | 2.8 mm - 4.0 mm | Power | DC 12V±25%, PoE (IEEE 802.3af) |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 80°, Rotate: 0° ~ 360° | Dimensions | 162 × 67 × 67mm (6.4” × 2.6” × 2.6”) (L x W x H) |
| Shutter | Auto/Manual, 1 ~ 1/100000s | Weight | 0.24kg (0.53lb) |
