Product Overview
UAC-B142-AF28(40)LM-DL
- • High quality imaging with 2MP resolution • TVI/AHD/CVI/CVBS • Supports IR-cut filter with auto-switch (ICR) • Smart Dual Light (only TVI) • 3D noise reduction technology delivers clean and sharp images • Supports 180° horizontal flip, 180° vertical flip • OSD configuration menu, easy to operate • IP67 waterproof and dustproof design, high reliability • OSD configuration menu in 11 languages • Built-in microphone for high quality audio transmission via coaxial cables.
Key Features
- 2 MP Resolution
- IR-cut filter with auto switch (ICR) Vision
Camera
Video & Audio
| Max Resolution | 2 MP | Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Sensor | 1/3.0" CMOS | Frame Rate | Main Stream: 2MP (1920*1080),Max 30fps; 720P (1280*720),Max 30fps Sub Stream: 640*360,Max 30fps; 2CI |
| Day/Night | IR-cut filter with auto switch (ICR) | Audio Compression | G.711U, G.711A |
| WDR | DWDR | Two-Way Audio | N/A |
Lens
General
| Focal Length | 2.8 mm - 4.0 mm | Power | DC 12V±25%, PoE (IEEE 802.3af) |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° | Dimensions | 162 × 67 × 67mm (6.4” × 2.6” × 2.6”) (L x W x H) |
| Shutter | Auto/Manual, 1 ~ 1/100000s | Weight | 0.24kg (0.53lb) |
